Trimming Saw Precision CS 70 EBG

Key Features

Precise height and tilt adjustment
Compatible with Festool guide rails for accurate rip cuts
CLEANTEC dust extraction for clean working environment
Multi Material Control electronics for speed adjustment
Robust design for heavy-duty applications

Specifications

Power consumption: 2,200 W
Voltage: 220–240 Volts / 50–60 Hertz
Saw blade diameter: 225 mm
Arbor Size: 30 mm
Maximum cutting height: 70 mm
Rip Cutting Width: 430 mm
Cross-cutting width: 830 mm (with sliding table)
Saw blade tilt angle: -2° to 47°
No-load speed: 4,200 rpm
Weight: approximately 37 kg
Machine dimensions: 690 × 500 × 340 mm

Main Applications

Rip and cross cuts for installation work.
Angled cuts and multi-material applications
Ideal for high-precision and heavy-duty work
