Feature
• 5 methods of unlocking.
• Remote unlock via Häfele Smart Living (using Wi-Fi)
• One set of administrator data for each element: fingerprint, key card, and password.
• 100 sets each of general user data, divided into: fingerprint and password.
• 200 sets of general user data (keycard data only)
• Key for opening (in case of emergency)
• 1 Megapixel door view camera with smart function
• Wide viewing angle of up to 120 degrees.
• The system will alert you if someone stands in front of the door for an extended period (more than 10 seconds).
• Two-way remote communication via application.
• High-precision radar sensor for person detection.
• 5000mAh Li-ion Battery
• Easy to control and configure via Häfele Smart Living application.
• Instructors voice over; offering both female and male voice overs
• A function to disable openning from outside (Privacy mode) and a function to allow free passage without locking (Passage mode)
• In case of battery ran out, it is possible to charge via USB Type-C from a Power Bank
• Can be installed on both left-openning and right-openning doors
• Can be installed on door frame with thickess 33–90 mm.
• Can be installed on 100 mm door frames.
• Environmental protection rating: Outer module IP65, Inner module IP53
Dimensions (WxHxD)
• Interior module: 74 x 344 x 78 mm
• Exterior module: 74 x 344 x 78 mm
• Mortise: 24 x 240 x 80 mm (Lock cylinder drilling distance: 60 mm)
Includes
• 1 set of interior and exterior modules
• 1 mortise lock set
• 3 striking plates
• 1 installation kit
• 2 key cards and 2 keychain key cards
• 2 emergency keys
• 1 user manual
• 1 drilling template
