Feature
• 5 methods of unlocking.
• Unlock with a Bluetooth key via the Häfele Smart Living application.
(Can connect to Multimode Gateway device 499.21.220 for remote unlocking and control of locking devices.)
• A total of 50 fingerprints for administrators and general users.
• Data from 100 administrator and general user key cards combined.
• 100 sets of passwords for both administrator and general users.
• Key for opening (in case of emergency)
• Easy to control and set up with the Häfele Smart Living application.
• Can be set to automatic lock mode or passage mode (always on).
• User instructions audio in English.
• Touch-sensitive digital buttons
• Random password entry function.
• Low battery warning function.
• Anti-theft system when multiple incorrect identity verifications are performed.
• Power supply: 4 x 1.5V AA manganese alkaline batteries (please order separately)
• In case the battery runs out, you can recharge it via USB Type-C from a power bank.
• Can be installed on both left and right opening doors.
• Can be installed on door panels 32–50 mm thick.
• Can be installed on 100 mm door frames.
Dimensions (W x H x D)
• Outer module dimensions: 75 x 163 x 75 mm.
• Inner module dimensions: 75 x 163 x 76 mm.
• Lock tongue: 25 x 57 x 85 mm (Adjustable mounting distance of 60 and 70 mm.)
Components
• 1 set of modules for both outside and inside.
• 1 set of throttle body springs
• 1 set of striking plates
• 1 set of installation kit
• 2 key cards
• 2 keychain key cards.
• 2 sets of spare keys (in case of emergency)
• 1 user manual
• 1 installation Guide
• 1 drilling template
