Feature
• 6 methods of unlocking
• Remote unlock via Häfele Smart Living (using Wi-Fi)
• One set of administrator data for each element: fingerprint, key card, and password.
• Store up to 100 sets of general users data such as: Face ID, fingerprint, key card, and password
• Key for opening (in case of emergency)
• 1 Megapixel door view camera with smart function
• Wide viewing angle of up to 120 degrees.
• The system will alert you if someone stands in front of the door for an extended period (more than 10 seconds).
• Two-way remote communication via application.
• 4-inch screen with a micro SD card slot (maximum capacity 32 GB)
• High-precision radar sensor for person detection.
• The fingerprint sensor is located under the handle.
• White LED lighting at door handle
• 5000mAh Li-ion Battery
• Easy to control and configure via Häfele Smart Living application.
• Instructor voice over; offers both male and female voice overs
• Privacy function to restrict access from the outside (Privacy mode) and a function to allow passage without unlocking (Passage mode).
• In case of battery ran out, it is possible to charge via USB Type-C from a Power Bank.
• Can be installed on both left-openning and right-openning door
• Can be installed on door frame with thickness 30–90 mm.
• Can be installed on door frames up to 120 mm.
• Environmental protection rating: Outer module IP65, Inner module IP53
Dimension (WxHxD)
• Exterior module: 69 x 404 x 61 mm.
• Interior module: 69 x 404 x 61 mm.
• Mortise: 24 x 240 x 99 mm. (Lock cylinder drilling distance: 60 mm)
Components
• โมดูลด้านนอกห้องและในห้อง 1 ชุด
• ตลับกุญแจ 1 ชุด
• เพลทรับกลอน 3 ชุด
• อุปกรณ์ติดตั้ง 1 ชุด
• คีย์การ์ด 2 ใบ และคีย์การ์ดแบบแขวนพวงกุญแจ 2 ใบ
• กุญแจสำรอง (กรณีฉุกเฉิน) 2 ชุด
• คู่มือเริ่มต้นการใช้งาน
• แผ่นทาบเจาะ 1 ชุด
Components:
• 1 set of Interior and Exterior module
• ตลับกุญแจ 1 ชุด
• 2 sets of striking plate
• 1 set of installation kit
• 2 key cards and 2 keychain key cards
• 1 user manual
• 1 drilling template
